905nm 50mW Multimode Infrared Laser Pigtailed Laser Diode

905nm 50mW Multimode Infrared Laser Pigtailed Laser Diode

[Specifications]
Wavelength: 905±10nm
Output Power: <50mW
Output Mode: Multimode
Multimode Coupling Ratio: >90%
Spot Form: Astigmatism
Fiber Core Diameter: 200um
Fiber Length: 1m (Customizeable)
Fiber Interface Type: FC/SMA905/LC/SC (Choose)
Fiber Material: Quartz
Coupling Lens Material: Optical glass
Operating Voltage: DC 2V
Operating Current: <90mA
Operating Voltage With Power Diver: DC 3~5V
Circuit Control Mode: ACC / TTL frequency modulation (Choose)
Operating Temperature: -10~50℃
Storage Temperature: -40~80℃
Size: Φ6*16mm
