532nm 8W Green Laser Module/Automatic refrigeration/High Power Green DPSS Laser

T532D8WD green laser show:

The imported laser diode pump source, T532D8WD DPSS green laser are made of high quality high quality nonlinear crystal and collimating lens, with temperature control of high performance driving power, the active temperature control, with high efficiency, good stability, good beam quality, low noise, strong anti-jamming, good consistency, compact structure, miniaturization, long life and so on.

Products are widely used in medicine, laser show, isotope separation, ultra-high density optical storage, precision materials processing, lithography, spectrum analysis etc..





Model: T532D8WD

Wavelength: 532nm

Operating mode:  CW

Output power:  >8W

Spatial mode:   Near TEM00

Longitudinal mode:  Multi

Spectral linewidth: Near 0.1nm

Polarization:  Linear vertical

Polarization ratio:  >100:1

Beam quality:   M2<1.8

Beam divergence full angle:   1.8mrad



Beam diameter at aperture:  3mm

Beam ellipticity:   1±0.1

Beam pointing stability:  0.03mrad

Power stability:       ±5% over 8 hrs rms

Optical axis height:   78mm

Size of laser head:    LxWxH=1805x150x125mm

Size of power supply:  LxWxH=238x146x102mm

Cabel-laser head:      1.0, 1.5m

Weight of laser head:  2.6kg

Weight of power supply:  2.3kg

TTL modulation: 0V-no lasing, 5V-lasing

Frequency of TTL:  1kHz-30kHz

Efficiency of TTL:  40%-60%

Analogue modulation:  0-5V

Frequency of analogue:  1kHz-10kHz

Cooling mode:      TEC

Operating votage:     90-260VAC

Maximum power consumption:  50W

Warm-up time:   15 mintues

Operating temperature:  0-35℃

Storage temperature:   -20-60℃(<90% relative humidity, non-condensing)

Expected life time:  10,000 hours

Warranty time:  1 year
