650nm 20mW~200mW Red Laser Diode Module Dot/Line/Crosshair Focus Adjustable Φ16X60mm

650nm 20mW~200mW Red Laser Diode Module Dot/Line/Crosshair Focus Adjustable Φ16X60mm

[Specification]
Product Name: Laser module
Wavelength: 650±10nm
Output Power: 20mW / 30mW / 50mW / 100mW / 200mW (Choose)
Laser Shape: Dot / Line / Crosshair (Choose)
Irradiation Range: <5m (indoor)
Diffusion Angle: >90°
Focus: Adjustable focus
Circuit Control: ACC (TTL Customizable)
Size: Φ16x60mm
Material: Aviation aluminum
Operating Voltage: Type 01: DC 2.8~5.2V / Type 02: DC 4.8~25V
Tail Wire: Type 01: DC female cable, the cable length is about 1m (Customizable)
                Type 02: 26# red and black electronic wire, about 15cm in length
Operating Current: <100mA (20mW),  <110mA (30mW),  <130mA (50mW),  <180mA (100mW),  <350mA (200mW)
Operating Temperature: -10℃~+50℃ (20-50mW), -30℃~+50℃ (100-200mW)
Storage Temperature: -20℃~+70℃ (20-100mW), -40℃~+70℃ (200mW),
Service Life: >10000 hours

[Package Include]
1 x Laser module
