1310nm 10dBm Semiconductor Optical Amplifier SM Fiber Amplifier Module Type SOA-1310-10-SM-M
Semiconductor optical amplifiers (SOA for short) are specially used for power amplification of optical signals in O-band, S-band, C-band, etc., with a typical small signal gain ≥25dB. The product has the characteristics of high gain, wide operating wavelength, low power consumption, low polarization-dependent loss, high extinction ratio, etc. SOA optical amplifiers can be used in laser radar, coherent detection, fiber optic sensing, optical communication and other fields, and can also be customized according to customer application requirements.
[Features]
Wide wavelength range
High gain factor
Low noise
[Applications]
Fiber optic communication
Fiber optic sensing
Fiber optic laser
[Specifications]
|
Parameters
|
Unit
|
Typical Value
|
Remarks
|
|
Model
|
--
|
SOA-1310-10-SM-M
|
|
|
Wavelength Range
|
nm
|
1310
|
|
|
Input power
|
dBm
|
-25~+10
|
|
|
Gain Spectrum Width@3dB
|
nm
|
≥60
|
@0dBm input
|
|
Saturated Output Power
|
dBm
|
≥10
|
@-10dBm Input
|
|
Small Signal Gain Factor
|
dB
|
>25
|
@-25dBm Input
|
|
Noise Figure
|
dB
|
≤8
|
|
|
Polarization Dependent Gain
|
dB
|
≤1
|
|
|
Polarization Mode Dispersion
|
ps
|
≤0.5
|
|
|
Isolation
|
dB
|
>30
|
|
|
Optical Power Monitoring
|
--
|
Output optical power monitoring
|
|
|
Fiber Interface Type
|
--
|
FC/APC
|
|
|
Pigtail Fiber Type
|
--
|
SMF-28e single-mode fiber
|
|
|
Work mode
|
--
|
Automatic Current Control (ACC) /
Automatic Power Control (APC)
|
|
|
Electrical and environmental parameters
|
Model Type
|
|
Control method
|
RS232 Serial communication
|
|
Communication interface
|
DB9 Female
|
|
Power supply
|
5V DC, <15W
|
|
Size
|
125(W)×150(D)×20(H)mm
|
|
Operating temperature range
|
-5~+35°C
|
|
Operating humidity range
|
0~70%
|
