1064nm 500mW 3kHz Ultra-narrow Line-width Laser SM Fiber Laser Benchtop NLFL-1064-500-T-SM-B
Single frequency narrow linewidth fiber laser adopts rare earth doped fiber DFB laser cavity structure, output single longitudinal mode laser with wavelength of 1064nm, spectral linewidth is less than 3kHz, output spectral side mode suppression ratio exceeds 60dB, can provide module or desktop package. It is distributed Ideal laser source for applications such as sensing.
[Features]
Spectral linewidth ≤ 3kHz
All-fiber DFB resonator
Wavelength stable without mode hopping
[Applications]
Lidar
Acoustic sensing, hydrophone
Optical fiber distributed sensing
[Specification]
|
Parameters
|
Unit
|
Typical Value
|
Remarks
|
|
Model
|
--
|
NLFL-1064-500-SM-B /
NLFL-1064-500-T-SM-B
|
T: Tunable power
|
|
Working Wavelength
|
nm
|
1064±0.1
|
*3dB line width = 20dB line width / 20
|
|
Spectral Linewidth
|
kHz
|
≤ 3
|
|
|
Sideband Suppression Ratio
|
dB
|
≥60
|
|
|
Wavelength instability
|
MHz
|
≤±25
|
|
|
Working Mode
|
-
|
CW, Single frequency single longitudinal mode
|
Continuous Laser
|
|
Output Power
|
mW
|
500
|
Fixed (Default) /
10~100% Output power Tunable(choose)
|
|
Short-term Stability (15 minutes)
|
dB
|
≤ ±0.02
|
Equivalent≤±0.5%
|
|
Long-term Stability (8 hours)
|
dB
|
≤ ±0.05
|
Equivalent≤±1.2%
|
|
Polarization State
|
--
|
Random polarization
|
|
|
Pigtail Fiber Type
|
--
|
Hi 1060 SM Fiber
|
L=1m
|
|
Fiber Interface Type
|
--
|
FC/APC
|
|
|
Electrical and environmental parameters
|
DeskTop Type
|
|
Control method
|
Button
|
|
Communication interface
|
DB9 Female(Default not include)
|
|
Power supply
|
AC 100~240V
|
|
Size
|
260(W)×320(D)×120(H)mm
|
|
Operating temperature range
|
-5~+35°C
|
|
Operating humidity range
|
0~70%
|
