520nm 1mW~1200mW Green Dot Laser Diode Module TTL Modulation 12x50mm

520nm 1mW~1200mW Green Dot Laser Diode Module TTL Modulation 12x50mm

[Specifications]
Product Name: Laser module
Output Wavelength: 520nm
Output Power:1mW ~ 1200mW (Choose)
Laser Shape: Dot
Modulation Frequency: 1HZ-100kHZ
Size: 12x50mm (Customizable)

520nm 1mW TTL Laser Module:
Operating Voltage: DC 2.8-5.2V
Modulation Voltage: DC 2.8-5.2V (0V off, 2.8-5.2V on)
Operating Current: ≤150mA
Irradiation Range:
Daytime Indoor: 0-300 meters
Daytime Outdoor: 0-100 meters
In the dark environment: 0-1000 meters

520nm 10mW TTL Laser Module:
Operating Voltage: DC 2.8-5.2V
Modulation Voltage: DC 2.8-5.2V (0V off, 2.8-5.2V on)
Operating Current: ≤200mA
Irradiation Range:
Daytime Indoor: 0-700 meters
Daytime Outdoor: 0-250 meters
In the dark environment: 0-2500 meters

520nm 35mW TTL Laser Module:
Operating Voltage: DC 2.8-5.2V
Modulation Voltage: DC 2.8-5.2V (0V off, 2.8-5.2V on)
Operating Current: ≤350mA
Irradiation Range:
Daytime Indoor: 0-1500 meters
Daytime Outdoor: 0-400 meters
In the dark environment: 0-4000 meters

520nm 50mW TTL Laser Module:
Operating Voltage: DC 2.8-5.2V
Modulation Voltage: DC 2.8-5.2V (0V off, 2.8-5.2V on)
Operating Current: ≤400mA
Irradiation Range:
Daytime Indoor: 0-2000 meters
Daytime Outdoor: 0-600 meters
In the dark environment: 0-5000 meters

520nm 85mW TTL Laser Module:
Operating Voltage: DC 3.5-5.2V
Modulation Voltage: DC 5V (0V off, 5V on)
Operating Current: ≤600mA
Irradiation Range:
Daytime Indoor: 0-2500 meters
Daytime Outdoor: 0-600 meters
In the dark environment: 0-6000 meters

520nm 150mW TTL Laser Module:
Operating Voltage: DC 9-25V
Modulation Voltage: DC 5V (0V off, 5V on)
Operating Current: ≤800mA
Irradiation Range:
Daytime Indoor: 0-3000 meters
Daytime Outdoor: 0-800 meters
In the dark environment: 0-7000 meters

520nm 1200mW TTL Laser Module:
Operating Voltage: DC 9-25V
Modulation Voltage: DC 5V (0V off, 5V on)
Operating Current: ≤1000mA
Irradiation Range:
Daytime Indoor: 0-5000 meters
Daytime Outdoor: 0-1000 meters
In the dark environment: 0-6000 meters
