520nm 5/10/20mW Dot Line Crosshair Green Laser Diode Module Focus Adjustable 12V/24V Φ16×120mm

520nm 5/10/20mW Dot Line Crosshair Green Laser Diode Module Focus Adjustable 12V/24V  Φ16×120mm

Our laser modules all use high-quality original and imported laser diodes, equipped with high-performance APC/ACC drive circuits and optically coated glass lens groups or high-quality plastic lens glue. They have the characteristics of high reliability, high stability, strong anti-interference, good consistency and long service life.

This product is mainly used for various mechanical processing, stone cutting positioning, tire production positioning, woodworking machinery, textile garment positioning, industrial instruments and equipment, laser light sources for line projection instruments, laser levelers, laser medical instruments, laser locators, etc.

[Specification]
Product Name: Laser module
Wavelength: 520nm
output Power: 5mW / 10mW /20mW (Choose)
Laser Shape: Dot / Line / Crosshair (Choose)
Operating Voltage: DC 12V /DC 24V (Choose)
Divergence Angle: 1.5mrad
Line Width: thinner at 0.5m, about 0.5mm; thinner at 1m, about 0.5mm.
Optical System: 3 spherical glass lenses
Curvature: ≤1mm @ 5m ( For Line/Corsshair laser module)
Operating Temperature: 10℃～35℃
Storage Temperature: -40℃～80℃
Size: Φ16mmx120mm
Continuous Working Time: 5 hours (@Good heat dissipation)

[Package Include]
1 x Laser module
1 x Power supply (Choose)
1 x Laser module holder (Choose)

Note:
The module is connected to a transformer, and the voltage is 12-24V. If no transformer is needed, the tail is a red and black power line, the red line is connected to the positive pole, and the black line is connected to the negative pole.
