905nm 20W Laser Diode 50μm Emitting Width TO56 Package 905C-50-20-0.75-TO

$8.50

Add to Cart:
Min:  20

905nm 20W Laser Diode 50μm Emitting Width TO56 Package 905C-50-20-0.75-TO

[Features]
High laser power
High efficiency.
Excellent beam characteristics.
Long lifetime, high reliability.

[Applications]
LiDAR
Measuring instruments
Security
Scientific rersearch

Note:
1. Lead time: Some chips are in stock, and it will take 2 to 3 weeks if there is no stock.
2. Wholesale price: >100 pcs order, please contact us, the price has a bigger discount.
3. Country of origin: Made In China

[Specifications]

Parameters

Symbol

Min.

Typical

Max.

Unit

Operation

Center wavelength

λ

895

905

915

nm

Output power

Po



20



W

Geometrical

Optical aperture size

w x h



50x10



μm²

Cavity length

L



750



μm

Chip width

W



300



μm

Chip height

H



150



μm

Electro Optical Data

Threshold current

Ith



0.4



A

Operating current

Iop



6



A

Operating voltage

Vop



7.6



V

Slow axis divergence FWHM

θ∥



14



degrees

Fast axis divergence FWHM

θ⊥



30



degrees

Spectral width FWHM

△λ



7



nm

Wavelength temperature coefficient

Δλ/ΔT



0.28



nm/℃




COS laser chip

COS laser chip

COS laser chip
