632nm 200MHz 1mm Clear Aperture Free Space Acousto-Optic Modulator AOM

632nm Free Space AOM

Product 4/5

Return to the Product List

632nm 200MHz 1mm Clear Aperture Free Space Acousto-Optic Modulator AOM

larger image

Starting at: $1,112.00

Please Choose:

Drive

Add to Cart:

632nm 200MHz 1mm Clear Aperture Free Space Acousto-Optic Modulator AOM

A free-space acousto-optic modulator is a device that combines sound and light signals for transmission, which can transmit signals without optical fibers. This technology is widely used in the field of wireless communication, such as wireless local area network, mobile communication and satellite communication.

[Applications]
Optical switch
Laser wavelength shift

Note:
Lead Time: 3~4 weeks

[Specifications]

Parameter	Unit	Min	Max	Typ.	Remarks
Material				TeO²
Wavelength	nm			632
Average Optical Power Density	W	250W/mm²
Ultrasonic Velocity	m/s			4200
Diffraction Efficiency	%		90	85
Center Frequency	MHz			200	Customizable
3dB Bandwidth	MHz			±20
Clear Aperture	mm			1	Customizable
RF Power	W			1.5
Rising Time	ns
Voltage Standing Wave Ratio
Input Resistance	Ω			50
Deflection Angle	mrad
Device Interface				SMA
Operating Temperature	℃			-10~+60
Storage Temperature	℃			-30~+70

free space AOM

free space AOM

free space AOM

free space AOM

free space AOM

free space AOM
