640nm 500mW Ultra Bright Red Laser Diode Module Dot/Line/Crosshair Focus Adjustable Φ16*70mm

640nm 500mW Ultra Bright Red Laser Diode Module Dot/Line/Crosshair Focus Adjustable Φ16*70mm

[Features]
The dot/line is clear and bright, soft and not dazzling, the size of the light spot and the line width are adjustable;
The angle of the line/cross lens is optional from 5°~120°;
The new imported tube core + special lens has high light transmission rate and small light energy loss;
The intelligent driver board with imported IC can be powered in a wide range, and other voltages can be customized;
The interior is filled with heat dissipation silicone and AB glue, which can fully dissipate heat and resist shock and fall;
The outer shell is aviation aluminum plated with insulating paint, anti-static;
High temperature resistant and corrosion resistant wires are suitable for all-weather and all-environment use;

[Specification]
Product Name: 640nm Laser Module
Wavelength: 640nm
Output Power: 500mW
Laser Shape: Dot / Line / Crosshair (Choose)
Operating Voltage: DC 6-25V
Operating Current: ≤500mA
Size: 16*70 mm

Dot module working distance:
Indoors during daylight: 0-2500 meters
Outdoors during daylight: 0-650 meters
In dark environments: 0-3500 meters

Line length of line laser module:
Indoor working environment: Max 22 meters
Semi-outdoor (not in direct sunlight): Max 10 meters
Outdoor (in direct sunlight): Max 4 meters
Installation height: 0~15 meters

Line length of crosshair laser module:
Indoors: Max 14 meters
Semi-outdoors (not in direct sunlight): Max 7 meters
Outdoors (in direct sunlight): Max 3 meters
Installation height: 0-15 meters

[Package Include]
1 x Laser module
1 x Power supply
1 x Laser holder
