660nm 5W 105μm*5 Fibers Beam Combining Module Red Fiber Coupled Laser

660nm 5W 105μm*5 Fibers Beam Combining Module Red Fiber Coupled Laser

The fiber beam combining module is a multi-core beam combining semiconductor laser. The large contact area and low current packaging form make the performance more stable and more convenient to use. The fiber parameters can be customized, and the built-in cooling plate will make the device performance more reliable and stable.

It is suitable for laser night vision, projection display, laser medical treatment, material testing and other fields

[Specifications]
Product Name: Fiber Coupled Laser
Wavelength: 660±5(nm)
Output Power: 5000mW
Fiber Core Diameter: 105μm*5
Numerical Aperture: 0.22
Fiber Connecter: FC/PC
Operating Current: 1.5A
Power Conversion Efficiency: 35~50%
Operating Voltage: ~12V
Operating Temperature: 10~35℃
Storage Temperature: -20~60℃
Operating Humidity: <60%
Lifetime: >10000 hours
