Multi Wavelength Laser 488nm-25mW 520nm-25mW 633nm-25mW 3IN1 SM Fiber Laser
[Specification]
Parameters
|
Unit
|
Typical value
|
Remarks
|
Model
|
--
|
FL-488/520/633-25-SM-B
|
|
Working Wavelength
|
nm
|
488/520/633
|
3IN1
|
Working Mode
|
--
|
CW
|
Continuous light
|
Output Power
|
mW
|
25/25/25
|
|
Power Adjustment Range
|
--
|
10~100%
|
Each wavelength is independently adjustable.
|
Short-term Stability (15 minutes)
|
dB
|
≤ ±0.02
|
Equivalent≤±0.5%
|
Long-term Stability (8 hours)
|
dB
|
≤ ±0.05
|
Equivalent≤±1.2%
|
Fiber Type
|
--
|
Nufern 460HP SM fiber
|
L=1m
|
Connector Type
|
--
|
FC/APC
|
|
Electrical and Environmental Parameters
|
Desktop Type
|
Control Method
|
Button
|
Communication Interface
|
DB9 Female
(Default not include)
|
Power Supply
|
AC 100~240V
|
Size
|
260(W)×320(D)×120(H)mm
|
Operating Temperature Range
|
-5~+35°C
|
Operating Humidity Range
|
0~70%
|
