905nm 225W Infrared Poweful Laser Diode TO9 Package 905E-300-225-0.75-TO
[Features]
5stack PLD
Laser wavelength: 905 nm
Peak output power:≥ 225W
Laser aperture (FWHM) size:240 μm x 19 μm
Laser aperture (enclosed 95%E) size : 300 μm
[Applications]
LiDAR
Laser ranging
Safety monitoring
Scientific research test
Note:
1. Lead time: Some chips are in stock, and it will take 2 to 3 weeks if there is no stock.
2. Wholesale price: >100 pcs order, please contact us, the price has a bigger discount.
3. Country of origin: Made In Chin
Absolute Maximum Ratings(Trt=25℃)
|
Parameters
|
Symbol
|
Value
|
Unit
|
|
Operation Current
|
Iop
|
45
|
A
|
|
Reverse voltage
|
Vr
|
20
|
V
|
|
Pulse Duration
|
Pw
|
100
|
ns
|
|
Duty ratio
|
DR
|
0.1
|
%
|
|
Operating Temperature
|
Top
|
-40~85
|
℃
|
|
Storage Temperature
|
Tstg
|
-40~105
|
℃
|
|
Soldering Temperature
|
Ts
|
≤260
|
℃
|
Characteristics (Trt=25 ℃)
|
Parameters
|
Symbol
|
Min.
|
Typ.
|
Max.
|
Unit
|
|
Peak Emission Wavelength
|
λop
|
895
|
905
|
915
|
nm
|
|
Spectral Bandwidth
|
BW
|
5
|
7
|
8
|
nm
|
|
Wavelenth Temperature Coefficient
|
Δλ/ΔT
|
-
|
0.065
|
0.09
|
nm/℃
|
|
Electro Optical Data
|
|
Operation Power
|
Pop
|
-
|
225
|
-
|
W
|
|
Operation Current
|
Iop
|
38
|
39
|
40
|
A
|
|
Turn-on Voltage
|
Von
|
-
|
6.8
|
-
|
V
|
|
Series Resistance
|
Rs
|
-
|
0.60
|
-
|
Ω
|
|
Threhold Current
|
Ith
|
-
|
0.8
|
-
|
A
|
|
Operation Voltage
|
Vop
|
29
|
30
|
31
|
V
|
|
Beam Divergenc(95%E)parallel to pn-junction①
|
θ∥
|
12
|
13
|
16
|
degrees
|
|
Beam Divergenc(FWHM)parallel to pn-junction②
|
θ∥
|
9
|
10
|
11
|
degrees
|
|
Beam Divergenc(95%E) perpendicular to pn-junction①
|
θ⊥
|
48
|
50
|
52
|
degrees
|
|
Beam Divergenc(FWHM) perpendicular to pn-junction②
|
θ⊥
|
22
|
23
|
24
|
degrees
|
|
Geometrical
|
|
Laser Aperture (95%E) Size①
|
w
|
-
|
300
|
-
|
μm
|
|
Laser Aperture（FWHM） Size②
|
w x h
|
-
|
240 x 19
|
-
|
μm2
|
|
Cavity Length
|
L
|
-
|
750
|
-
|
μm
|
|
Chip Width
|
W
|
-
|
400
|
-
|
μm
|
|
Chip Height
|
H
|
-
|
150
|
-
|
μm
|
Notes: ①Full width at 95% power content；②Full Width at half maxima
.jpg)
.jpg)
.jpg)
