405nm 5mW~400mW Blue-violet Laser Module Dot Ultra-small Perfect Circle Φ12*50mm/Φ16*82mm

405nm 5mW~400mW Blue-violet Laser Module Dot Ultra-small Perfect Circle    Φ12*50mm/Φ16*82mm

The front end of the module adopts an optically coated glass lens group to create an ultra-small full-circle spot effect, which has the characteristics of high light passing rate, small beam divergence angle, high parallelism, and uniform brightness.

[Features]
◆ The spot size can be adjusted from 0.4 mm to several centimeters to meet your different requirements;
◆ The light spot is clear and bright, soft and not dazzling;
◆ Brand new imported core, can be turned on 24 hours a day;
◆ Intelligent driver board with imported IC, which can supply power in a wide range, and other voltages can be customized;
◆ The interior is filled with heat dissipation silica gel and AB glue, which can not only fully dissipate heat, but also resist shock and drop;
◆ The shell is made of aviation aluminum plated with insulating paint, which can not only fully dissipate heat, but also be shockproof, anti-drop and anti-static;
◆ High temperature resistant and corrosion resistant wires, suitable for all-weather and all-environment use;

[Specification]
Product Name: Laser module
Wavelength: 405nm
Output Power: 5~400mW (Choose)
Laser Shape: Super small round spot
Optical Lens: Optical coated glass lens group imported from Germany
Working Voltage: DC 2.8-5.2V
Working Current: ≤ 2000mA
Focus: Fixed / Adjustable (Choose)
Size: Fixed focus：Φ12*50mm / Adjustable focus: Φ16*82mm

Spot Size:
1-10 meters adjustable small circle spot: 2.5mm
10-20 meters adjustable small circle spot: 3.5mm
20-50 meters adjustable small circle spot: 5mm
50-80 meters adjustable small circle spot: 8mm
80-100 meters adjustable small circle spot: 10mm

Note: Peripheral aperture and stray light are not included

[Package Include]
1 * Laser module
1 * Power supply
1 * Laser module holder
