1590nm 40dBm 10W Single-mode Fiber Laser Source Benchtop FL-1590-40-SM-B
The 1590nm single-wavelength laser adopts a high-performance butterfly semiconductor laser chip, and the professionally designed drive and temperature control circuit control ensures the safe operation of the laser and stable output power and spectrum. Suitable as a pump laser source for thulium-doped fiber lasers or fiber amplifiers.
[Features]
DFB cavity laser
Power and spectral high stability
Narrow spectral line width
Adjustable output power
Module or desktop package
[Applications]
Thulium-doped fiber laser
Optical fiber sensing
Optical Fiber Communication
Optical experiment
Note:
Lead time: About 5 weeks.
[Specification]
|
Parameters
|
Unit
|
Typical Value
|
Remarks
|
|
Model
|
--
|
FL-1590-40-SM-B
|
|
|
Working Wavelength
|
nm
|
1590
|
|
|
Spectral Linewidth
|
nm
|
≤ 0.1
|
|
|
Sideband Suppression Ratio
|
dB
|
>50
|
|
|
Working Mode
|
--
|
CW
|
Continuous Laser
|
|
Output Power
|
W
|
10
|
40dBm
|
|
Power Adjustment Range
|
--
|
10~100%
|
|
|
Short-term Stability (15 minutes)
|
dB
|
≤ ±0.02
|
Equivalent≤±0.5%
|
|
Long-term Stability (8 hours)
|
dB
|
≤ ±0.05
|
Equivalent≤±1.2%
|
|
Pigtail Fiber Type
|
--
|
SMF-28 SM Fiber
|
L=1m
|
|
Fiber Interface Type
|
--
|
FC/APC
|
|
|
Electrical and environmental parameters
|
DeskTop Type
(Current product)
|
Module Type
|
|
Control method
|
Button
|
RS232 Serial communication
|
|
Communication interface
|
DB9 Female(Default not include)
|
DB9 Female
|
|
Power supply
|
AC 100~240V
|
DC 12V, 10A
|
|
Size
|
260(W)×320(D)×120(H)mm
|
139(W)×235(D)×70(H)mm
|
|
Operating temperature range
|
-5~+35°C
|
|
Operating humidity range
|
0~70%
|
