1030nm 40dBm 10W Powerful PM Fiber Laser Source Benchtop FLH-1030-40-PM-B
This laser adopts all-fiber laser technology, professionally designed and driven temperature control circuit and control to ensure the safe operation of the laser and stable laser output power and spectrum. It is suitable as a seed laser for higher power laser systems, and can also be used for production testing of optical fiber devices. It can be provided in benchtop or modular packaging.
[Features]
High output power
Power and spectral stability
Polarization-Maintaining output
[Applications]
Seed Laser
Fiber Laser
Optical device testing
[Specifications]
|
Parameters
|
Unit
|
Typical value
|
Remarks
|
|
Model
|
--
|
FLH-1030-40-PM-B
|
|
|
Working Wavelength
|
nm
|
1030±2
|
|
|
Spectral Width
|
nm
|
<0.2
|
|
|
Output Power
|
W
|
10
|
Customizable
|
|
Power Adjustable Range
|
--
|
10~100%
|
|
|
Short-term Stability (15 minutes)
|
dB
|
≤ ±0.02
|
|
|
Long-term Stability (8 hours)
|
dB
|
≤ ±0.05
|
|
|
Pigtail Type
|
--
|
PM980 Polarization-maintaining fiber
|
L=1m
|
|
Pigtail Connector Type
|
--
|
FC/APC
|
For power test only
|
|
Electrical and Environmental Parameters
|
Desktop Type
|
|
Control Method
|
Button
|
|
Communication Interface
|
DB9 Female
(Default not include)
|
|
Power Supply
|
AC 100~240V
|
|
Size
|
260(W)×320(D)×120(H)mm
|
|
Operating Temperature Range
|
-5~+35°C
|
|
Operating Humidity Range
|
0~70%
|
