1250~1650nm Ultra-Broadband SLD Light Source Single-mode Fiber Laser Benchtop SLD-2565-25-SM-B
The ultra-broadband SLD light source uses multiple waveband superradiance light sources to perform spectral splicing and combination to achieve single-mode fiber output covering the ultra-broadband spectrum of 1250-1650nm wavelength, and at the same time has a high optical power spectral density. Suitable for passive device testing, optical fiber sensing and other applications.
Flatness is about 15dB, fixed optical power is not adjustable, single-mode fiber output.
[Features]
Ultra wide spectrum
Low spectral ripple
Stable power
[Applications]
Optical fiber sensing
Medical Imaging
Optical fiber device testing
[Specifications]
|
Parameters
|
Unit
|
Typical value
|
Remarks
|
|
Model
|
--
|
SLD-2565-25-SM-B
|
|
|
Spectral Range
|
nm
|
1250~1650
|
|
|
Ouput Power
|
mW
|
≥10
|
When PER is added, the output power will be reduced.
|
|
Spectral Power Density
|
dBm/nm
|
≥-25
|
|
|
Spectral Ripple
|
dB
|
<0.2
|
|
|
Short-term Stability (15 minutes)
|
dB
|
≤ ±0.02
|
Equivalent≤±0.5%
|
|
Long-term Stability (8 hours)
|
dB
|
≤ ±0.05
|
Equivalent≤±1.2%
|
|
PER (Polarization Extinction Ratio)
|
dB
|
≤ 0.2
|
Adding PER results in reduced output power.
eg: 10mW SLD, after adding PER, the output power becomes about 8.5mW.
|
|
Pigtail Type
|
--
|
SMF-28 Single mode fiber
|
Ф=3mm loose tube, L=1m
|
|
Pigtail Connector Type
|
--
|
FC/APC
|
|
|
Electrical and Environmental Parameters
|
Desktop Type
|
|
Control Method
|
Button
|
|
Communication Interface
|
DB9 Female
(Default not include)
|
|
Power Supply
|
AC 100~240V
|
|
Size
|
260(W)×280(D)×120(H)mm
|
|
Operating Temperature Range
|
-5~+35°C
|
|
Operating Humidity Range
|
0~70%
|
