1053nm 1000mW DPSS Laser IR Lab Laser System CW&TTL/Analog Modulation

1053nm 1000mW DPSS Laser IR Lab Laser System CW&TTL/Analog Modulation

[Specifications]
Product Name: 1053nm IR DPSS Laser
Lead Time: 1~3 weeks,Custom product available!
Output Wavelength: 1053±1nm
Output Power: 1000mW
Operate Mode: Near TEM00
Operating Mode: CW or Modulation
Pointing Stability: <0.05 mrad
Beam Diameter (1/e²): <3 mm
Beam Divergence (Full Angle): <2 mrad
Beam Quality(M²): <2
Power stability: <±3% per 2 hrs
Beam Height: Near 29mm
Temperature Stabilizing: TEC
Warm Up Time: <5 minutes
Optimum Operating Temperature: 20~30℃
Storage Temperature: 10~50℃
MTTF(mean time to failure): 10,000 hrs
Modulation: 0~30khz Analog or TTL
Laser Head Dimension: Near 155(L)x77(W)x60(H) mm³ (Click here find detail)
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Standard Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Warranty: 1 Year

[Applications]
Thermal printing
Material Inspection
Scanning Biochemistry
Lidar

[Package Include]
1 x 1053nm Laser head
1 x Laser power supply
