980nm 10W High power IR Semiconductor Laser with power supply

980nm 10W High Power IR Semiconductor Laser with power supply



Product Name: 980nm IR Semiconductor Laser

Lead Time: 1~3 weeks! Custom product available!

Output Wavelength: 980(+/-5) nm

Output Power: 10000mW
Spatial Mode: Multi-mode

Operating mode: CW or Modulation

Prejudiced way: 10:1

Pointing Stability: <0.05 mrad

Beam diameter:  near 6mm

Beam Divergence Angle:  2.5 mrad

Power stability: <±3% per 2 hrs

Bean Height:  near 29mm

Temperature Stabilizing: TEC

Warm Up Time: <5 minutes

Beam quality(M2): <2

Optimum Operating Temperature: 20~30℃

Storage Temperature: 10~50℃

MTTF(mean time to failure): 10,000 hrs

Laser Head dimension: Near 155(L)*77(W)*60(H)mm3 (Click here find detail)
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Standard Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Modulation: 0~30KHz Analog or TTL

Warranty: 1 Year



1 x 980nm IR  Laser

1 x Laser power supply
