25.5° 42.6° Dotted Lines Union Jack Pattern Laser Red/Green/Blue Module

25.5° 42.6° Dotted Lines Union Jack Pattern Laser Red/Green/Blue Module

[Features]
1. Ultra high brightness, universal in indoor and outdoor.
2. The light is clear and bright, soft and not dazzling.
3. Spot size is adjustable.
4. The shell is made of aviation aluminum-plated insulating paint that can not only fully dissipate heat but also resist shock, drop, and static electricity.
5. Imported laser diodes emit light directly with exceptional stability.
6. Intelligent driver board with imported IC, wide range power supply.
7. High temperature resistance, corrosion resistance.

[Specifications]
Product Name: Laser Module
Laser Color: Red / Green / Blue (Choose)
Power: 100mW
Installation Height: 0~5 meters
Working Voltage: DC 2.8V~5.2V
Working Current: <500mA
Dimensions: 16*70mm
Optical Lens: Grating sheet (imported from Germany)

25.5° Dotted Lines Laser Module
X direction: 25.5°
At 0.5 m, the length in the X direction is 226 mm.
Y direction: 14.1°
At 0.5 meters, the length in the Y direction is 124 mm.
Oblique direction: 28.9°
At 0.5 meters, the length in the diagonal direction is 258 mm.

42.6° Dotted Lines Laser Module
X direction: 42.6°
At 0.5 meters, the length in the X direction is 390 mm.
Y direction: 24.4°
At 0.5 meters, the length in the Y direction is 216 mm.
Oblique direction: 49.8°
At 0.5 meters, the length in the diagonal direction is 464 mm.

[Package Include]
1 x Laser module
1 x Power supply
1 x Laser module holder
