1480nm 400mW SM Fiber Output Laser for Pump Laser Module Type FL-1480-400-SM-M
The 1480nm wavelength laser adopts high-performance semiconductor laser chips, and the professionally designed drive and temperature control circuit control ensures the safe operation of the laser and stable output power and spectrum. Suitable as a pump laser source for fiber lasers or EDFA fiber amplifiers, available in benchtop or modular packages.
[Features]
1. High output power
2. Power and spectral stability
3. Module or desktop package
[Applications]
Fiber Laser
Erbium-Doped Fiber Pumping
Optical test
[Specifications]
|
Parameters
|
Unit
|
Typical value
|
Remarks
|
|
Model
|
--
|
FL-1480-400-SM-M
|
|
|
Working Wavelength
|
nm
|
1480±10
|
|
|
Working Mode
|
--
|
CW
|
Continuous light
|
|
Output Power
|
mW
|
400
|
Customizable
|
|
Power Adjustable Range
|
--
|
10~100%
|
|
|
Short-term Stability (15 minutes)
|
dB
|
≤ ±0.02
|
Equivalent≤±0.5%
|
|
Long-term Stability (8 hours)
|
dB
|
≤ ±0.05
|
Equivalent≤±1.2%
|
|
Pigtail Type
|
--
|
SMF-28 Single mode fiber
|
L=1m
|
|
Pigtail Connector Type
|
--
|
FC/APC
|
|
|
Electrical and Environmental Parameters
|
Desktop Type
|
Module Type
(Current product)
|
|
Control Method
|
Button
|
RS232 Serial communication
|
|
Communication Interface
|
DB9 Female
(Default not include)
|
DB9 Female
|
|
Power Supply
|
AC 100~240V
|
DC 5V, 3A
|
|
Size
|
260(W)×280(D)×120(H)mm
|
125(W)×150(D)×20(H)mm
|
|
Operating Temperature Range
|
-5~+35°C
|
|
Operating Humidity Range
|
0~70%
|
