High Power Fiber Laser Source 1550nm 10W Single-mode Fiber Laser Benchtop FLH-1550-40-SM-B
The 1550nm band single-wavelength laser light source (high power) uses DFB semiconductor laser chip, with high-power gain optical path module to achieve single-mode fiber high-power output, professionally designed drive circuit and TEC control to ensure safe and stable laser operation.
[Features]
DFB cavity laser
Power and spectral high stability
Adjustable output power
Module or desktop package
[Applications]
Optical fiber sensing
Optical Fiber Communication
Optical experiment
[Specification]
|
Parameters
|
Unit
|
Typical Value
|
Remarks
|
|
Model
|
--
|
FLH-1550-40-SM-B
|
|
|
Working Wavelength
|
nm
|
1550±0.5
|
1540~1570nm Customizable
|
|
Spectral Linewidth
|
nm
|
≤ 0.1
|
|
|
Sideband Suppression Ratio
|
dB
|
≥50
|
|
|
Working Mode
|
-
|
CW
|
Continuous Laser
|
|
Output Power
|
W
|
10
|
40dBm
|
|
Power adjustment range
|
-
|
10~100%
|
|
|
Short-term Stability (15 minutes)
|
dB
|
≤ ±0.02
|
Equivalent≤±0.5%
|
|
Long-term Stability (8 hours)
|
dB
|
≤ ±0.05
|
Equivalent≤±1.2%
|
|
Pigtail Fiber Type
|
--
|
SMF-28 SM Fiber
|
L=1m
|
|
Fiber Interface Type
|
--
|
FC/APC
|
|
|
Electrical and environmental parameters
|
DeskTop Type
(Current product)
|
Module Type
|
|
Control method
|
Button
|
RS232 Serial communication
|
|
Communication interface
|
DB9 Female(Default not include)
|
DB9 Female
|
|
Power supply
|
AC 100~240V
|
DC 12V, 10A
|
|
Size
|
376(W)×340(D)×112(H)mm
|
139(W)×235(D)×70(H)mm
|
|
Operating temperature range
|
-5~+35°C
|
|
Operating humidity range
|
0~70%
|
