808nm 50mW SM Fiber Coupled Laser Single Mode TEM00 Laser

808nm 50mW SM Fiber Coupled Laser Single Mode TEM00 Laser

[Specifications]
Product Name: 808nm Fiber Coupled Laser
Lead Time: 1~3 weeks
Output Wavelength: 808±5nm
Output Power: 50mW (at Laser head)
Spatial Mode: TEM00
Operating Mode: CW or Modulation
Power Stability: <3% per 2 hrs
Temperature Stabilizing: TEC
Warm Up Time: <5 minutes
MTTF(mean time to failure): 10,000 hrs
Fiber Type: Single-mode fiber/SM fiber
Fiber Interface(Output): FC/PC, FC/APC, SMA905(choose)
Fiber Length: 1m (Default)
Laser Head Dimension: Near 100(L)x40(W)x50(H)mm3 (Click here find detail)
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Standard Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Modulation: 0~30kHz Analog or TTL
Warranty: 1 Year

[Package include]
1 x 808nm Fiber coupled laser
1 x Single mode optical fiber
1 x Laser power supply

Note:
The marked output power is before coupling, coupling efficiency is about 40%.
