Fiber Coupling for 980nm 500mW Laser Single Mode and CW/Modulation Together
This product is for single mode fiber coupling of semiconductor laser,the stability of the output power of the fiber is good and the spot mode is TEM00 mode.The beam quality is very good, which can meet the requirement of high beam quality.
Our company produces single wavelength, polarization maintaining and multimode fiber coupled lasers at various wavelengths, as well as fiber optic coupled lasers with fiber coupled lasers.Please contact us.
Notes:
This is a custom product,.If you need other output powe or have special requirements, please contact us.
Lead Time: 7~15 workingdays! Custom product available!
[Features]
1.High power stability(<3%)
2.Singal mode fiber coupled,fiber output.
[Specifications]
Wavelength:980nm±5nm
Output Power:500mW (@ Fiber output side, and 0~max power adjustable)
Operating Temperature: 0°C-40°C
Storage Temperature: -40°C-85°C
Modulation: 0~10KHz TTL
| Parameter |
Work condition |
Symbol |
Min. |
Typical Value |
Max. |
Unit |
| Output Power |
@PO |
PO |
|
|
500 |
mW |
| Power Stability |
2hrs |
Ps |
|
|
3 |
% |
| Central Wavelength |
@PO |
λc |
|
980 |
|
nm |
| Spectral linewidth |
@PO |
FWHM |
|
2 |
|
nm |
| Fiber Type |
SM Fiber |
| Fiber Length |
|
|
|
100 |
|
cm |
| Fiber interface |
|
|
FC/APC |
|
| Warming Time |
@PO |
Tw |
|
|
5 |
minute |
| Noise |
RMS(10Hz-100MHz) |
N |
|
1 |
|
% |
| Service Life |
@PO |
MTBF |
10000 |
|
|
Hrs |
