638nm 6W Red Fiber Coupled Laser Strong Laser Beam

638nm 6W Red Fiber Coupled Laser Strong Laser Beam



[Specifications]
Product Name: 638nm 6W Fiber coupled laser
Lead Time: 1~3 weeks
Output Wavelength: 638nm±5 nm
Output Power: 6000mW
Operating Mode: CW or Modulation
Power Stability: <±5% per 4 hrs
Temperature Stabilizing: TEC
Warm Up Time: <5 minutes
MTTF(mean time to failure): 10,000 hrs
Fiber Type: Multi-mode fiber/MM fiber
Fiber Core Diameter: 100μm/200μm/400μm/600μm/800μm/1000μm (Choose)
Fiber Numerical Aperture: 0.22NA(100μm~400μm)/0.37NA(600μm~1000μm)
Fiber Interface(Output): FC/PC, FC/APC, SMA905 (Choose)
Fiber Length: 1m/2m/3m (Choose)
Laser Head Dimension: Near 175(L)*92(W)*60(H)mm3  (Click here find detail)
Power Supply: Standard type power supply / Lab Adjustable power supply (Choose)
Power Supply-1: Standard Power Supply (Choose) (Click here find detail)
Power Supply-2: Lab Adjustable Power Supply (Choose) (Click here find detail)
Laser Radiator/Heat Sink: Not Include/Include (Choose) (Click here find detail)
Modulation: 0~30kHz Analog or TTL
Warranty: 1 Year



[Package Include]
1 x 638nm Fiber coupled  Laser
1 x Laser power supply



Note: The marked output power is before coupling, coupling efficiency is about 80%~90%.
